120V AC LED ESTRIP

Product Category 120V120V

Illuminate spaces with the 120V AC LED eStrip, the optimal lighting solution tailored for both residential and commercial settings. Designed for simplicity, this LED eStrip enhances any indoor or outdoor area without the need for an additional driver.

Key Features:

  • Direct 120V AC Input: Simplifies installation by directly connecting to line voltage.
  • High Efficiency: Offers high light efficiency with superior lumens and power factor.
  • Safety First: Features constant current design and overvoltage protection. Includes temperature control to prevent overheating (up to 55°C).
  • Flexibility in Lighting: Fully dimmable with TRIAC technology for adjustable ambiance.
  • Easy Installation: No transformer required for AC to DC conversion, plus easy connection with bared power cords.
  • Durable Material: Crafted through an IP65 PVC extrusion process for longevity.
  • Wide Range: Supports a minimum section of 4 inches to a maximum run of 164FT.
  • Certifications and Warranty: ETL certified with a 5-year warranty for indoor and 3-year for outdoor use.

Applications:

  • Outlining buildings and architectural features.
  • Enhancing signage visibility.
  • Adding atmospheric lighting to decks.

Where to buy

Share this product:
Product code ES-120V-27K-164FT ES-120V-30K-164FT ES-120V-40K-164FT
Electrical Input Voltage 120V AC
Power Consumption 4W/Ft
Specs Colour Temperature 2700K 3000K 4000K
Efficacy 280LM 300LM 340LM
CRI 90+
Dimmable Yes
LED Type SMD2835
Life Span 30,000 hours
Spacing N/A
# per foot (304mm) 18LEDs
Design Dimensions .79” W (20mm)
Max Single Run Length 50M (164 Ft)
Custom Cuttable Cuttable every 10CM (3 15/16”) – Factory only
Approved Location Indoor/Outdoor
Warranty 5 years warranty indoor use; 3 years warranty outdoor use
Approvals cETLus
